Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision

Brand Name : DAD

Model Number : DE2A-L

Place of Origin : China

MOQ : 1 piece

Price : $478.41

Payment Terms : L/C,T/T

Supply Ability : 1 ~ 10 day

Delivery Time : 10 work day

Contact Now


Product Paramenters

Products Description

Model and Specification

DE2A-L

Telescope


Erect

Magnification

30x

Objective aperture

47mm

Field of view

1°30

Shortest viewing distance

1m

Stadia ratio

100

Resolution

3.75

Angle measurement

Angle measurement mode

Absolute angle encoder system

Minimum count

1/5/10/20

Angle units

DEG/MIL/GON

Accuracy

2/5/10

Display

LCD

LCD double sides

compensator

Compensation range

±3′

Resolution

1″

Up laser point

Wavelength

635nm

Laser focusingpoint

5mm/100m

Deviation between laser focusing point and telescope collimation axis

≤5″

Valid optical distance

150m(Day)

Down Point type

Down Laser plummet

Precision of plate vial

30″/2mm

Precision of circular vial

8′/2mm

Working Temperature

-20鈩�~+50鈩�

Power

Battery

Chargeable NiMH battery

Voltage

6.0V

Instrument weight

6.5kg

Volume

180mm×166mm×355mm
